This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention.
External Device Connections
You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.
Open Platform Support
Our SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on our displays.
Pixel Shifting
Pixel Shifting is designed to be activated inside the SoC in order to prevent for potential risk of image sticking, caused by constant content. With this feature turned on, pixels on the screen will move in an interval while causing no interference of visual experience.
SoC Content Management
With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems.
Signal Failover
Our SoC Software has a protection for “No Signal” scenario. If the USB is unplugged after your content is set to be displayed with USB, the display will either show your customized banner or search for any other signal from other sources (HDMI, Display Port, etc.). This failover protection is constructed for higher user experience.
Scheduler
Digital Signage Monitor Software allows many important features such as Scheduler. Scheduler sets your display turn on/off time easily and lets you not to worry about the status of your displays in any time.
Subtle Design
This series’ displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, detachable power plug, carrying handles and IR extender.
Usb Auto-Play
You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.
Display Control
Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time.
External ControlRS232 (3.5mm jack green), Fast Ethernet (RJ45), Service (RJ12)
Mechanical
Product Dimensions (WxDxH)734 x 78 x 435 mm
Package Dimensions (WxDxH)795 x 128 x 530 mm
Product Weight4.5 kg
Package Weight6 kg
Vesa Mounting75 x 75 mm M4
Bezel WidthB:21, T/ L/R:14 mm
Condições ambientais
Operating Temperature0-40°C
Operating Humidity10-90%
Poder
Power Supply170 VAC - 240 VAC - 50/60 Hz
Consumo de energia
Typical32 W
Maximum65 W
Deep Standby≤0.5 W
Features
Main FeaturesHTML5 CMS Launcher, Android CMS Launcher, Open Content Management Support, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock, OSD and UI Rotation, Video Rotation, NoSignalPowerOff, Pixel shift, Scheduler, Videowall support, Remote control via LAN, Real Time Clock, SNMP
Mechanical FeaturesJoystick, Fixed IR lens, Rocker Switch, Detachable Power Cable
Speaker2x6 W
Acessório
StandardQSG, IB, Power cord, Remote control unit, RC battery, Mounting kit, IR extender cable
Certificação
SafetyYes
EMCYes
CEYes
* As especificações estão sujeitas a alterações sem aviso prévio.
