Sèrie VN

VN43B/4H

Discontinued Products
CONSULTA PER COMPRAR
Característiques
IP Streaming Support

Our processors in the displays make it easier to manage content through many devices. IP video streaming protocols such as RTSP/RTP/HLS and UDP Multicast are supported for real-time content streaming. So that, live broadcasts can be displayed in this way.

Auto Launch

We have made it easy to give any HTML5-based application link to the display within the SoC software. Upon this, the display will start with the given link. The application can either be an offline or an online application, allowing the customers to execute their own application.

Source Switching

It is made available to set any Source on startup of the display. It can also be switched on any other signal source using scheduler and failover scenarios. This lets the users to freely control the process of their requirements allowing best user experience.

Usb Auto-Play

You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.

Image Orientation

SoC Software lets you choose the orientation of the display menu easily. This feature is important for portrait usage of our professional panel monitors.

External Device Connections

You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.

Scheduler

The built in scheduler is one of the many important included features. The scheduler allows you to plan daily routines of when the display is powered on or off, along with selection of different sources or USB playlists.

HDMI Wake Up

To maximize the user experience while using external video devices such as mediaplayers, display controllers or PCs, all our devices have HDMI Wakeup feature ready to turn on/off the display by simply pluging/unplugging the HDMI cable.

Pixel Shifting

The Pixel Shifting feature can be activated in order to reduce the potential risk of image sticking when static content is displayed over long periods of time. The feature periodically shifts the image on the display, without causing any interference of the visual experience.

Specification Sheet Fitxa de dades comercials Dibuix mecànic detallat
Especificacions
Mostra
Screen Size 43"
Backlight Type Edge-Type LED
Brightness (typical) 500 cd/m²
Native Resolution UHD: 3840 x 2160 - HDR10
Contrast Ratio (typical) 1200:1
Dynamic Contrast Ratio 50000:1
Life Time (typical) 50000 Hrs
Response Time (typical) 8 ms
Active Area (H x V) 941 x 529 mm
Viewing Angle 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Color Value 1.07 B (10-bit)
Screen Treatment 3H
Haze Level 1%
Refresh Rate 60 Hz
Front Type Ultra Narrow Bezel
Orientation Horizontal / Portrait
Operation Hours 24/7
Area of Usage Indoor
Sistema incorporat
Mainboard Model 17MB135VS
E/S posteriors
RGB Input VGA(DE-15F)
RGB Output N/A
Video Input 4xHDMI2.0, 2xUSB2.0
Audio Input Line In L/R
Audio Output Headphone, Optic SPDIF
External Control RS232(DE-9F), Ethernet(RJ45), Service(RJ12)
External Sensor RJ12
Mechanical
Product Dimensions (WxDxH) 965 x 67 x 558 mm
Package Dimensions (WxDxH) 1195 x 145 x 775 mm
Vesa Mounting 200 x 200 mm
Bezel Width B:11 | T:7 | L/R:7 mm
Condicions ambientals
Operating Temperature 0-40°C
Operating Humidity 10-90%
Poder
Power Supply 110 VAC - 240 VAC - 50/60 Hz
Consum energètic
Typical 96 W
Maximum 120 W
Deep Standby ≤0.5 W
Features
Main Features Open Content Management Support, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock, OSD Rotation, NoSignalPowerOff, Screen Saver, Pixel shift, Scheduler, Videowall support, remote control via LAN, Real Time Clock
Mechanical Features Joystick, Cable Holder
Accessoris
Standard QSG, IB, Power Cord, Remote Control Unit, RC Battery, Mounting Kit
Certificació
Safety YES
EMC YES
CE YES
* Les especificacions estan subjectes a canvis sense avís previ.
